Kongming HV

Kongming is a hyperdimensional computing library implementing sparse binary hypervectors for cognitive computing applications.

The Python package of kongming-rs-hv is released under MIT license, essentially no limitation (and assumes no liability) to any use, personal or commercial.

The core engine is implemented in Go / Rust for maximum efficiency, while ergonomic APIs are open-sourced in Python, for better usability.

We do have an internal Go/Rust APIs that interacts directly with the core engine: overall all APIs maintains minimalistic abstractions and wire-identical serialization.

See Hypervectors for an introduction to hyperdimensional computing and the sparse binary representation.

License

MIT License

Install

pip install kongming-rs-hv

See Installation for supported platforms and verification steps.

Published notebooks

See Notebook Platforms for all available notebooks and platform details.

Guides

Language Support

This documentation covers code snippets in multiple languages (if available) side by side.

• Python: bindings to the underlying Rust implementation (public kongming-rs-hv on PyPI);
• Go: canonical / reference implementation in proprietary package;
• Rust: parallel implementation, carefully maintained in feature parity;

Reference

The work was initially outlined in this arxiv paper, built on top of the work from many others, and here is the citation:

Yang, Zhonghao (2023). Cognitive modeling and learning with sparse binary hypervectors. arXiv:2310.18316v1 [cs.AI]

Feedback

Found a bug, have a question, or want to suggest an improvement? Open an issue on GitHub.

Hypervectors

What is Hyperdimensional Computing?

Hyperdimensional computing (HDC) represents concepts as high-dimensional vectors and manipulates them with simple algebraic operations, typically the dimension (of any vectors) can be as high as thousands.

The key insight is that random vectors in high-dimensional spaces are nearly orthogonal — giving each concept a unique, distributed, and robust representation that tolerates potential ambiguity and interference.

In that sense, the traditional notion of curse of dimensionality becomes the bless of dimensionality.

Motivated readers should perform their own background research on this topic.

Sparse Binary Representation

Kongming uses sparse binary hypervectors. Each vector has a fixed, large number of dimensions (e.g., 65,536/64K or 1,048,576/1M), but only a very small fraction of them are “on” (set to 1). This sparsity is controlled by the Model configuration.

Furthermore, we focus on a special sparse binary configuration: SparseSegmented where each vector is divided into equal-sized segments, and exactly one bit is ON per segment.

Conceptually you can imagine each SparseSegmented hypervector as a list of phasers, where the offset of ON bit (within a host segment) represents the discretized phase.

In general, this unique constraint enables:

• Compact storage: only the offset of ON bit within its host segment need to be stored
• Efficient operations: Unlike neural nets, where weights are recorded in float numbers, binary operations can be stored and manipulated very efficiently with modern memory / CPUs.

Identity and Inverses

• The identity vector has all offsets set to 0. Binding with identity is a no-op. Actually as a special case, there is no storage cost;
• Binding a vector with its inverse yields the identity.

Similarity and distance measure

Two vectors are compared via overlap — the count of segments where both have the same ON bit. This is equivalent to a bitwise AND operation, which can be performed very efficiently in modern CPU.

For a model with cardinality $k$ and segment size $s$, the expected overlap between two random vectors $A$ and $B$ is:

$$\text{E}[O(A,B)]=Ns=1$$

Given the model setup, this is typically 0, 1 or 2.

Semantically-related vectors have significantly higher overlap. A vector’s overlap with itself equals its cardinality $M$.

The commonly-used distance measure (dis-similar measure) for binary vectors is Hamming Distance, equivalent to a bitwise XOR operation. As we discussed (and proved) in the paper, the overlap and Hamming distance between sparse binary hypervectors are two sides of the same coin, with the following equation:

$$2\times O(A,B)+H(A,B)=2M$$

Supported Models

A Model determines the total number of dimensions (width), how those dimensions are divided into segments (cardinality and sparsity), and therefore implies critical storage and compute characteristics.

Model properties

All model functions take a Model enum value and return the derived property:

How to Choose a Model

• MODEL_64K_8BIT: Fast prototyping, tiny memory footprint. Good for tests and small-scale experiments.
• MODEL_1M_10BIT: General-purpose, balances performance and storage.
• MODEL_16M_12BIT: General-purpose, for the adventurous.
• MODEL_256M_14BIT / MODEL_4G_16BIT: Very high capacity, not there yet.

Larger models provide more orthogonal space (lower collision probability) at the cost of more memory per vector.

Operators

Kongming provides two core algebraic operations on hypervectors.

Bind

Binding ($\otimes$) combines two vectors into a result that is dissimilar to both inputs. It is the multiplicative operation in the HDC algebra.

Mathematically

$$A\otimes B=B\otimes A\text{(commutative)}$$

$$(A\otimes B)\otimes C=A\otimes (B\otimes C)\text{(associative)}$$

$$A\otimes I=A\text{(where I is an identity vector)}$$

$$A\otimes A^{-1}=I\text{(inverse)}$$

$$O(A\otimes B,A)\approx O(A\otimes B,B)\approx \text{noise}\text{(dissimilarity)}$$

Implementation: segment-wise offset addition modulo segment size: check out original paper for details.

Check out code snippets from the API reference.

Release

Occasionally we use release, which is derived from bind, as the equivalent of division, as opposed to multiplication.

$$A\oslash B=A\otimes B^{-1}$$

Note that release is anti-commutative: $$(A\oslash B{)}^{-1}=B\oslash A$$

Check out code snippets from the API reference.

Bundle

Bundling ($\oplus$) creates a superposition of vectors — the result is similar to all inputs. It is the additive operation within VSA algebra.

Mathematically

$$S=\sum _{i,\oplus }{A}_i$$

$$O(S,A_i)\gg O_{\text{random}}\text{(similarity to each member)}$$

$$O(S,X)\approx O_{\text{random}}\text{for }X\notin \{A_i\}\text{(dissimilarity to non-members)}$$

Check out original paper for details on bundle operator.

Check out code snippets from the API reference.

Composites

Composites combine multiple hypervectors into higher-level structures. Each composite type uses a different combination strategy, preserving different kinds of relationships between its members.

All composites follows the same contract (interface in Go and traits in Rust) and can be nested — a Set can contain Sparkles, Knots, or even other Sets.

Set

An unordered collection of concepts.

$$S=S_{marker}\otimes (\sum _{i,\oplus }{M}_i)$$

where $S_{marker}$ is a special marker to distinguish a set from its individual members.

This mark is tuned for the domain, so that it will be shared among all sets within the same domain.

Use when: you need to represent “these things together” without order.

Check out code snippets from the API reference.

Sequence

An ordered collection.

$$S=S_{marker}\otimes (\sum _{i,\oplus }{M}_i\otimes S_{step}^i)$$

where $S_{step}$ is a generic hypervector for positional encoding.

$S_{marker}$ is a special marker to distinguish a sequence from its individual members. This mark is tuned for the domain, so that it will be shared among all sequences within the same domain.

Use when: order matters (e.g., words in a sentence, events in time).

Check out code snippets from the API reference.

Octopus

A key-value structure. Each key (a string) is converted to a Sparkle and bound with its corresponding value before bundling.

$$S=\sum _{i,\oplus }{K}_i\otimes V_i$$

Use when: you need to represent structured records with named attributes.

Check out code snippets from the API reference.

Knot

The result of binding (multiplicative composition) of hypervectors.

$$S=\prod _{i,\otimes }{M}_i$$

Binding is reversible: given a Knot of A and B, you can recover A by releasing B (binding with B’s inverse).

Use when: you need a reversible association between concepts.

Check out code snippets from the API reference.

Parcel

The result of bundling (additive composition).

$$S=\sum _{i,\oplus }{M}_i$$

Unlike direct bundling, Parcel keeps tracking of its members for serialization and introspection.

Use when: you need a superposition of concepts, with optional weights.

Check out code snippets from the API reference.

Summary

Near Neighbor Search

Near Neighbor Search (NNS) generally retrieves chunks from the storage substrate in the increasing order of Hamming distance (from a query).

As we mentioned earlier, this is equivalent to a strictly decreasing order of overlap (between query and candidate). If overlap encodes the semantic relevance, this translates to a list of semantically similar candidates.

It leverages an underlying Associative Index for efficient recovery of candidates. The Associative Index is a semantic index that enables fast similarity-based lookup over stored hypervectors. Conceptually it turns a key-value substrate (item memory) into an associative memory — one where retrieval is by content similarity, not by exact content or key match.

This NNS module has a constant time complexity, with help from associative index. This implies the query time remain bounded, independent of the number of entries in the storage system. The secret sauce is the efficient random-access to underlying associative index.

Unlike approximate nearest neighbor methods (LSH, HNSW, etc.), the NNS module can computes exact overlap counts via the associative index. There is no approximation error and no index-specific parameters to tune.

Jump to the API reference for Near-Neighbor Search.

HV

The core hypervector API. This module provides the building blocks for hyperdimensional computing: vector types, algebraic operators, and model configuration.

Common Utilities

Functions and types used across all HyperBinary types.

Models

See Concepts: Hypervectors for the full overview.

Model Enum

model0 = hv.MODEL_64K_8BIT

model1 = hv.MODEL_1M_10BIT

model0 := api.Model_MODEL_64K_8BIT

model1 := api.Model_MODEL_1M_10BIT

#![allow(unused)]
fn main() {
let model0 = Model::Model64k8bit;

let model1 = Model::Model1m10bit;
}

Model Functions

hv.width(hv.MODEL_1M_10BIT)           # total dimensions
hv.cardinality(hv.MODEL_1M_10BIT)     # ON bit count
hv.sparsity(hv.MODEL_1M_10BIT)        # sparsity
hv.segment_size(hv.MODEL_1M_10BIT)    # dimensions per segment

hv.Width(hv.MODEL_1M_10BIT)           // total dimensions
hv.Cardinality(hv.MODEL_1M_10BIT)     // ON bit count
hv.Sparsity(hv.MODEL_1M_10BIT)        // sparsity
hv.SegmentSize(hv.MODEL_1M_10BIT)     // dimensions per segment

#![allow(unused)]
fn main() {
let model = Model::Model1m10bit;
model.width()             // total dimensions
model.cardinality()       // ON bit count
model.sparsity()          // sparsity
model.segment_size()      // dimensions per segment
}

See also: SparseOperation — Model + seeded RNG for deterministic vector generation.

Domain & Pod

A Domain models the semantic grouping for hypervectors, providing the high 64-bit half of a Seed128. A Pod is a slot within a Domain, providing the low 64-bit half. The (Domain, Pod) pair uniquely identifies a Sparkle.

Domain Constructors

# From a name string (hashed to a 64-bit id)
d = hv.Domain("animals")

# Same as above
d = hv.Domain.from_name("animals")

# From a raw 64-bit id
d = hv.Domain.from_id(0x1234567890abcdef)

# From a domain prefix enum and a name suffix
# The id is computed as xxhash(prefix_label + "." + name)
d = hv.Domain.from_prefix_and_name(hv.DOMAIN_PREFIX_NLP, "concept")

# Accessors
d.id()              # u64
d.name()            # str (empty if constructed from id)
d.domain_prefix()   # int (0 = UNKNOWN if no prefix was set)
d.is_default()      # True if id == 0

d := hv.NewDomain("animals")
d := hv.NewDomainByID(0x1234567890abcdef)
d := hv.NewDomainWithPrefix(api.DomainPrefix_NLP, "concept")

#![allow(unused)]
fn main() {
let d = Domain::from_name("animals");
let d = Domain::from_id(0x1234567890abcdef);
let d = Domain::with_prefix(DomainPrefix::Nlp, "concept");
}

Domain Prefix Constants

Domain prefixes provide namespacing for domains. When a prefix is set, the domain id is derived from the prefix label (and optional name), ensuring consistent hashing across languages.

Pod Constructors

Pods can be seeded by a string word, a raw uint64, or a prewired enum value.

# From a word string (hashed to a 64-bit seed)
p = hv.Pod("cat")

# Same as above
p = hv.Pod.from_word("cat")

# From a raw 64-bit seed
p = hv.Pod.from_seed(42)

# From a prewired enum value
p = hv.Pod.from_prewired(hv.PREWIRED_SET_MARKER)
p = hv.Pod.from_prewired(hv.PREWIRED_STEP)

# Accessors
p.seed()       # u64
p.word()       # str (empty if constructed from seed or prewired)
p.prewired()   # int (0 if not prewired)
p.is_default() # True if seed == 0

p := hv.NewPodByWord("cat")
p := hv.NewPodBySeed(42)
p := hv.NewPodByPrewired(api.Prewired_SET_MARKER)

#![allow(unused)]
fn main() {
let p = Pod::from_word("cat");
let p = Pod::from_seed(42);
let p = Pod::from_prewired(Prewired::SetMarker);
}

Prewired Constants

Prewired pods are infrastructure-level constants with fixed seeds:

Seed128

A Seed128 is a 128-bit seed to drive a random number generator.

The current random number generator expects 2 64-bit seeds: the same (seed_high, seed_low) pair always produces the same sequence of random numbers, enabling reproducible and deterministic vector generation across runs and languages.

Constructors

# From Domain and Pod arguments (each accepts Domain/Pod, int, or str)
seed = hv.Seed128("animals", "cat")                # domain name + pod word
seed = hv.Seed128(0, 42)                           # default domain + raw pod seed
seed = hv.Seed128("animals", 42)                   # domain name + raw pod seed
seed = hv.Seed128(hv.Domain("animals"), hv.Pod("cat"))  # explicit Domain/Pod objects

# Zero seed
seed_zero = hv.Seed128.zero()                      # (0, 0)

# Random seed from a SparseOperation
seed_rand = hv.Seed128.random(so)                  # consumes two u64 from the RNG

# Accessors
seed.domain()                                      # Domain object
seed.pod()                                         # Pod object
seed.high()                                        # u64 (domain id)
seed.low()                                         # u64 (pod seed)

seed := hv.NewSeed128(0, 42)          // from raw uint64 values
seedZero := hv.Seed128Zero()          // zero seed
seed1 := hv.NewSeed128FromDP(hv.NewDomain("domain"), hv.NewPodByWord("pod"))

#![allow(unused)]
fn main() {
let seed = Seed128::new(0, 42);     // from raw u64 values
let seedZero = Seed128::zero();         // zero seed
}

Usage

All composite constructors take a Seed128, as seed for the bundle operator:

seed = hv.Seed128("fruits", "fruit_set")

s = hv.Set(seed, a, b, c)
seq = hv.Sequence(seed, a, b, c)

seed := hv.NewSeed128(0, 42)

s := hv.NewSet(seed, a, b, c)
seq := hv.NewSequence(seed, 0, a, b, c)

#![allow(unused)]
fn main() {
let seed = Seed128::new(0, 42);

let s = Set::new(seed, vec![a, b, c]);
let seq = Sequence::new(seed, 0, vec![a, b, c]);
}

SparseOperation

A SparseOperation instance wraps a Model, a random number generator, and potentially other information related to the sparse operation in general.

Constructor

so = hv.SparseOperation(hv.MODEL_1M_10BIT, 0, 42)
so1 = hv.SparseOperation(hv.MODEL_1M_10BIT, "domain", "pod")

so := hv.NewSparseOperation(api.Model_MODEL_1M_10BIT, 0, 42)

#![allow(unused)]
fn main() {
let mut so = SparseOp::new(Model::Model1m10bit, 0, 42);
}

Methods

so.model()        # Model enum

so.width()        # width for this model

so.cardinality()  # cardinality for this model

so.sparsity()     # sparsity for this model

so.uint64()       # next random number

so.Model()        // api.Model

so.Width()        // width for this model

so.Cardinality()  // cardinality for this model

so.Sparsity()     // sparsity for this model

so.Uint64()       // next random number

#![allow(unused)]
fn main() {
so.model()        // Model

so.width()        // width for this model

so.cardinality()  // cardinality for this model

so.sparsity()     // sparsity for this model

so.uint64()       // next random number
}

Usage: Generating Random Vectors

so = hv.SparseOperation(hv.MODEL_1M_10BIT, 0, 42)
sparkle = hv.Sparkle.random(hv.Domain("domain"), so)

so := hv.NewSparseOperation(api.Model_MODEL_1M_10BIT, 0, 42)
sparkle := hv.NewRandomSparkle(domain, so)

#![allow(unused)]
fn main() {
let mut so = SparseOp::new(Model::Model1m10bit, 0, 42);
let sparkle = Sparkle::random(&domain, &mut so);
}

Utilities

Similarity

hv.overlap(a, b)    # Overlap

hv.hamming(a, b)    # Hamming distance

hv.equal(a, b)      # Equality check

hv.Overlap(a, b)         // Overlap

hv.Hamming(a, b)         // Hamming distance

hv.Equal(a, b)           // Equality check

#![allow(unused)]
fn main() {
overlap(&a.core(), &b.core())   // Overlap

hamming(&a.core(), &b.core())   // Hamming distance

hyper_binary::equal(&a, &b)     // bool
}

Identity Check

v=hv.Sparkle.identity(model)

hv.is_identity(v)   # True if v is an identity vector

v := hv.NewSparkleIdentity(model)

hv.IsIdentity(v)    // True if v is an identity vector

#![allow(unused)]
fn main() {
v.is_identity()     // True if v is an identity vector
}

Hash Utilities

hv.hash64_from_string("hello")   # deterministic u64 hash from string
hv.hash64_from_bytes(b"\x01\x02") # deterministic u64 hash from bytes
hv.curr_time_as_seed()            # current time as a u64 seed
hv.kongming_studio_seed()         # fixed studio seed constant

hv.Hash64FromString("hello")     // uint64
hv.Hash64FromBytes(raw)          // uint64
hv.Hash64FromMessage(protoMsg)   // uint64 — hash from protobuf message
hv.CurrTimeAsSeed()              // uint64

#![allow(unused)]
fn main() {
hash64_from_string("hello")      // u64
hash64_from_bytes(&raw)          // u64
curr_time_as_seed()              // u64
KONGMING_STUDIO_SEED             // u64
}

HyperBinary Types

All vector types conform to a common interface. In Go this is the HyperBinary interface; in Rust it is the HyperBinary trait. The two implementations are kept at feature parity.

v.model()        # Model enum
v.width()
v.cardinality()
v.hint()
v.stable_hash()  # int
v.seed128()
v.exponent()

v.core()         # SparseSegmented
v.power(p)       # HyperBinary

type HyperBinary interface {
    Model() api.Model
    Width() uint32
    Cardinality() uint32
    Hint() api.HyperBinaryProto_Hint
    StableHash() uint64
    Seed128() Seed128
    Exponent() int32

    Core() SparseSegmented
    Power(p int32) HyperBinary
}

#![allow(unused)]
fn main() {
pub trait HyperBinary: std::fmt::Display {
    fn model(&self) -> Model;
    fn width(&self) -> u32;
    fn cardinality(&self) -> u32;
    fn hint(&self) -> HyperBinaryHint;
    fn stable_hash(&self) -> u64;
    fn seed128(&self) -> &Seed128;
    fn exponent(&self) -> i32;

    fn core(&self) -> SparseSegmented;
    fn power(&self, p: i32) -> HyperBinaryKind;
}
}

Concrete Types

SparseSegmented 🍡

The most foundational vector type — a sparse binary hypervector where each segment has exactly one ON bit at the recorded offset location. All other types (Sparkle, Set, Sequence, etc.) ultimately contain a SparseSegmented in memory for processing.

Structure

The offsets are bit-packed according to the model’s sparsity bits — they do not align to byte boundaries. This trades a small CPU cost for compact, uniform storage that works both in memory and on disk.

Identity vector: when offsets is blank, the vector is the identity vector where all offsets are 0. Binding with identity is a no-op, and identity requires zero storage for offsets.

Constructors

# Identity
ss = hv.SparseSegmented.identity(model)

# From raw offsets, typically discouraged...
ss = hv.SparseSegmented(model, offsets_bytes)

// Identity
ss := hv.NewSparseSegmentedIdentity(model)

// From raw offsets (takes ownership of slice)
ss := hv.NewSparseSegmented(model, offsets)

#![allow(unused)]
fn main() {
// Identity
let ss = SparseSegmented::identity(model);

// From raw offsets (takes ownership)
let ss = SparseSegmented::new(model, Some(offsets));
}

Key Methods

ss.is_identity()  # True if identity vector

ss2 = ss.power(2)
inv = ss.power(-1)

# Similarity
hv.overlap(a, b)   # Count of matching ON bits
hv.hamming(a, b)   # Count of differing segments

ss.offsets()   # returns all offsets

ss.IsIdentity()   // bool

ss2 := ss.Power(2).(hv.SparseSegmented)
inv := ss.Power(-1).(hv.SparseSegmented)

// Similarity
a.Overlap(b)   // uint32
a.Hamming(b)   // uint32

// offset access.
ss.On(idx)         // Check if a specific global index is ON
ss.Offset(seg)     // Get the offset within a segment

// Iterate over all (segment, offset) pairs
for seg, offset := range ss.OffsetIter() {
    // ...
}

#![allow(unused)]
fn main() {
ss.is_identity()  // bool

let ss2 = ss.power(2);
let inv = ss.power(-1);

// Similarity
a.overlap(&b)   // u32
a.hamming(&b)   // u32

// offset access.
ss.on(idx)          // bool
ss.offset(seg)      // u32

for (seg, offset) in ss.offset_iter() {
    // ...
}
}

Serialization

SparseSegmented serializes to HyperBinaryProto with hint SPARSE_SEGMENTED. The offsets field carries the raw packed bytes. Identity vectors serialize with empty offsets.

Sparkle ✨

Sparkles are the atomic building block for higher-level constructs: essentially SparseSegmented annotated with domain and pod.

Domain is a logical namespace that groups related Sparkle instances. Pod acts as the secondary identifier for a Sparkle instance.

Sparkle is deterministic: the same (domain, pod) pair always produces the same offsets. For this reason, the (model, pod) pair uniquely identifies a Sparkle.

Sparkle Constructors

# From a word string
s0 = hv.Sparkle.from_word(model, "animals", "cat")

# From a numeric seed
s1 = hv.Sparkle.from_seed(model, "animals", 42)

# From a prewired enum
s2 = hv.Sparkle.from_prewired(model, "animals", hv.PREWIRED_SET_MARKER)

# Identity vector
s3 = hv.Sparkle.identity(model)

# Random (from SparseOperation)
so=hv.SparseOperation(hv.MODEL_1M_10BIT, "domain", "pod")
s4 = hv.Sparkle.random("animals", so)

// From a word string
s0 := hv.NewSparkleWithWord(model, domain, "cat")

// From a numeric seed
s1 := hv.NewSparkleWithSeed(model, domain, 42)

// From a prewired enum
s2 := hv.NewSparkleWithPrewired(model, domain, api.Prewired_SET_MARKER)

// Identity vector
s3 := hv.NewSparkleIdentity(model)

// Random (from SparseOperation)
s4 := hv.NewRandomSparkle(domain, so)

#![allow(unused)]
fn main() {
// From a word string
let s0 = Sparkle::with_word(model, domain, "cat");

// From a numeric seed
let s1 = Sparkle::with_seed(model, domain, 42);

// From a prewired enum
let s2 = Sparkle::with_prewired(model, domain, Prewired::SetMarker);

// Identity vector
let s3 = Sparkle::identity(model);

// Random (from SparseOperation)
let s4 = Sparkle::from_random(domain, &mut so);
}

Key Methods

s0.model()         # Model enum
s0.stable_hash()   # Deterministic hash
s0.exponent()      # Current exponent (1 for base vector)

s0_square=s0.power(2)     # Returns p-th power (new Sparkle)
hv.equal(s0, s0_square)   # s0_square = s0^2, different from original s0.

core0=s0.core()     # Returns underlying SparseSegmented
core0.offsets()    # The raw offsets for each segment.

s0.Model()         // api.Model
s0.StableHash()    // uint64
s0.Exponent()      // int32

s0Square := s0.Power(2)  // HyperBinary (cast to Sparkle)
s0Square.Core()          // SparseSegmented

#![allow(unused)]
fn main() {
s0.model()         // Model
s0.stable_hash()   // u64
s0.exponent()      // i32

let s0_square = s0.power(2)        // Sparkle
s0.core()          // SparseSegmented
}

Pretty-printing

# Pretty-printing, or s.__str__()
print(s0)
# ✨:🔗animals,🌱cat

# More detailed information, or s.__repr__()
s
# hint: SPARKLE
# model: MODEL_1M_10BIT
# stable_hash: 9725717137035622833
# domain:
#   name: animals
# pod:
#   word: cat

During pretty-printing of Sparkle instances, you may notice special emoji for domain / pods.

Learner 💫

Learners are designed to perform online bundling for a stream of observations, in the form of Hebbian-style learning.

The total storage / processing budget is fixed — what matters is the distribution of weights among observed vectors.

Constructors

learner = hv.Learner(model, hv.Seed128(0, 42))

# a randomly-initialized learner.
learner = hv.Learner.random(so)

learner := hv.NewLearner(model, hv.NewSeed128(0, 42))

// a randomly-initialized learner.
learner := hv.NewRandomLearner(so)

#![allow(unused)]
fn main() {
let mut learner = Learner::new(model, Seed128::new(0, 42));

// a randomly-initialized learner.
let mut learner = Learner::random(&mut so);
}

Feeding Observations

learner.bundle(a)                 # single observation

learner.bundle_multiple(b, 3)     # with weight multiplier

learner.Bundle(a)                 // single observation

learner.BundleMultiple(b, 3)      // with weight multiplier

#![allow(unused)]
fn main() {
learner.bundle(&a)?;              // single observation

learner.bundle_multiple(&b, 3)?;  // with weight multiplier
}

Inspection

learner.age()             # number of observations seen

learner.weight(a)     # implicit weight for a probe vector

learner.Age()             // uint32

learner.Weight(a)     // float64

#![allow(unused)]
fn main() {
learner.age()             // u32

learner.weight(&a)    // f64
}

Set 🫧

An unordered collection of hypervectors. See Composites: Set for the conceptual overview.

Constructor

s = hv.Set(hv.Seed128(0, 42), first, second, third)

s := hv.NewSet(hv.NewSeed128(0, 42), first, second, third)

#![allow(unused)]
fn main() {
let s = Set::new(Seed128::new(0, 42), members);
}

Notable methods

# All these will be approximately 1/3 of the total cardinality.
hv.overlap(s.unmasked(), first)
hv.overlap(s.unmasked(), second)
hv.overlap(s.unmasked(), third)

Sequence 📿

An ordered collection of hypervectors with positional encoding. See Composites: Sequence for the conceptual overview.

Constructor

# Constructing a sequence, with logical index start at 1 (default to 0).
seq = hv.Sequence(hv.Seed128(0, 42), first, second, third, start=1)

seq := hv.NewSequence(hv.NewSeed128(0, 42), 1, first, second, third)

#![allow(unused)]
fn main() {
let seq = Sequence::new(Seed128::new(0, 42), 1, members);
}

Octopus 🐙

A key-value composite where each value is bound with its key’s Sparkle. See Composites: Octopus for the conceptual overview.

Constructor

oct = hv.Octopus(hv.Seed128(0, 42), ["color", "shape"], red, circle)

oct := hv.NewOctopus(hv.NewSeed128(0, 42), []string{"color", "shape"}, red, circle)

#![allow(unused)]
fn main() {
let oct = Octopus::new(Seed128::new(0, 42), keys, values);
}

Key Methods

oct.value_by_key("color") # returns the value, or raises ValueError

oct.ValueByKey("color")  // HyperBinary — lookup by key

#![allow(unused)]
fn main() {
oct.value_by_key("color")  // Option<&HyperBinaryKind>
}

Knot 🪢

The result of binding (multiplicative composition) of hypervectors. Unlike BindDirect, Knot tracks its member parts for serialization and debugging. See Composites: Knot.

Constructor

# Not directly constructed in Python. Use hv.bind() instead.
k = hv.bind(a, b)

k := hv.NewKnot(hv.NewSeed128(0, 42), partA, partB)

// More commonly via the Bind operator:
k := hv.Bind(a, b)

#![allow(unused)]
fn main() {
let k = Knot::new(Seed128::new(0, 42), parts);
}

Parcel 🎁

The result of bundling (additive composition) of hypervectors. Unlike BundleDirect, Parcel tracks its members and bundling seed for serialization and debugging. See Composites: Parcel.

Constructors

p = hv.bundle(hv.Seed128(10, 1), a, b, c)

p := hv.NewParcel(hv.NewSeed128(0, 42), partA, partB, partC)

#![allow(unused)]
fn main() {
let p = Parcel::new(Seed128::new(0, 42), parts);
}

Operators

See Concepts: Operators for the full overview.

Bind

bound = hv.bind(a, b)
released = hv.release(bound, b)  # this will recover `a`

hv.equal(a, b)                   # hash equality

bound := hv.Bind(a, b)
recovered := hv.Release(bound, b)        // this will recover `a`

eq := hv.Equal(a, b)                     // bool

#![allow(unused)]
fn main() {
let bound = operators::bind_hb(vec![a.clone(), b.clone()]); // Knot
let recovered = operators::release(&bound, &b);             // this will recover `a`

let eq = hyper_binary::equal(&a, &b);                       // bool
}

Release

Extracts one component from a binding: $A\oslash B=A\otimes B^{-1}$

bound = hv.bind(role, filler)
recovered = hv.release(bound, role)  # ≈ filler

bound := hv.Bind(role, filler)
recovered := hv.Release(bound, role)  // ≈ filler

#![allow(unused)]
fn main() {
let bound = operators::bind_hb(vec![role.clone(), filler.clone()]);
let recovered = operators::release(&bound, &role);
}

Bundle

p = hv.bundle(hv.Seed128(10, 1), a, b, c)

p := hv.Bundle(hv.NewSeed128(10, 1), a, b, c)

#![allow(unused)]
fn main() {
let p = operators::bundle(Seed128::new(10, 1), vec![a, b]);
}

Customizing runtime behavior

Environment Variables

All environment variables are read once on first access and cannot be changed at runtime. Unset variables use the documented default.

KONGMING_RNG

Selects the pseudo-random number generator backend used for hypervector generation.

Changing this affects all generated vectors: Sparkle offsets, Learner bundling, Cyclone patterns. Vectors generated with different backends are not comparable.

KONGMING_REPR_FORMAT

Controls __repr__() / Repr() output format.

KONGMING_LEARNER_SAMPLING

Controls the bundling strategy used by Learner.

# Example: use PCG for backward compatibility with pre-v3.7.5 vectors
export KONGMING_RNG=pcg

# Example: switch repr to protobuf debug format
export KONGMING_REPR_FORMAT=PROTO

# Example: use classic sampling in Learner
export KONGMING_LEARNER_SAMPLING=CLASSIC

Querying the Current Environment

Use global_env() to inspect all active settings at runtime. Returns a GlobalEnv protobuf message — new fields added to the proto automatically appear.

>>> hv.global_env()
rng_hint: XOSHIRO256PP
learner_sampling: FISHER_YATES
repr_format: YAML

Misc

Display

All HyperBinary types have a compact, emoji-prefixed string representation for quick visual inspection. See HyperBinary Types for type symbols and Sparkle for field labels.

Python __str__ and __repr__

__str__ (triggered by print()) returns the compact emoji form:

>>> a = hv.Sparkle.with_word(hv.MODEL_64K_8BIT, hv.d0(), "hello")
>>> print(a)
✨:🌐0x..c862,🫛0x..80e4

__repr__ (triggered by evaluating a variable in the shell or notebook) returns a detailed, developer-friendly YAML representation, controlled by the KONGMING_REPR_FORMAT environment variable:

>>> a
hint: SPARKLE
model: MODEL_64K_8BIT
stable_hash: 12345678
domain:
  id: ...
pod:
  seed: 12345

Set KONGMING_REPR_FORMAT=PROTO for protobuf debug output instead of the default YAML. See Environment Variables for all supported variables.

Go / Rust Display

print(sparkle)      # compact emoji form via __str__
repr(sparkle)       # detailed YAML/proto form via __repr__

// Compact emoji form
fmt.Println(sparkle)          // ✨:🌐0x..c862,🫛0x..80e4

// Detailed YAML/proto form (controlled by KONGMING_REPR_FORMAT env)
fmt.Println(sparkle.Repr())

#![allow(unused)]
fn main() {
// Compact emoji form (via Display trait)
println!("{}", sparkle);      // ✨:🌐0x..c862,🫛0x..80e4
}

Serialization

# HyperBinary → protobuf bytes
msg = hv.to_message(sparkle)

# protobuf bytes → HyperBinary
obj = hv.from_message(msg)

# raw proto bytes → HyperBinary
obj = hv.from_proto_bytes(data)

# proto bytes → YAML string (for debugging)
hv.format_to_yaml(data)

// HyperBinary → proto
pb, err := sparkle.ToProto(ctx)

// YAML formatting
yaml := hv.FormatToYaml(protoMsg)

#![allow(unused)]
fn main() {
// HyperBinary → proto
let pb = sparkle.to_proto();

// proto → HyperBinary
let sparkle = Sparkle::from_proto(&pb)?;
}

Memory

The memory package provides persistent and in-memory storage for hypervectors with semantic indexing and near-neighbor search.

The core abstraction is a Chunk — an immutable identity (Sparkle) paired with a mutable semantic code (any HyperBinary). Chunks are stored in a Substrate (pluggable storage backend), queried via ChunkSelectors, and created via ChunkProducers.

Chunk

The fundamental storage unit in the memory system. A Chunk pairs an immutable identity (always a Sparkle) with a mutable semantic code (any HyperBinary type).

The unique id for a chunk facilitates the compositionality, as this chunk is either present or absent. At the same time, the potentially learnable code (for a chunk) offers opportunities to learn and adapt, just like weights from traditional neural nets.

Structure

Inspection

Chunks are typically created via producers (see Producers), but can be inspected after retrieval (see Selectors).

# chunk = memory.first_picked_chunk(view, memory.by_item_key("animals", "cat"))

chunk.id        # Sparkle
chunk.code      # HyperBinary
chunk.note      # str
chunk.extra     # Optional[bytes]

Substrate & Views

A Substrate is a pluggable storage backend. It provides transactional views for reading and writing chunks.

View Pattern

All storage access goes through views:

• SubstrateView — read-only, supports key lookup and prefix scanning
• SubstrateMutableView — extends SubstrateView with write staging and atomic commit (to underlying storage)

# Read-only view (context manager)
with storage.new_view() as view:
    # Check if chunk exists, without actually reading it back.
    exists = view.chunk_exists("animals", "cat")

    cat_chunk = view.read_chunk("animals", "cat")

# Mutable view (auto-commits on clean exit, rollback on exception)
with storage.new_mutable_view() as view:
    view.write_chunk(sparkle, code=some_code, note="my note")

    # commits automatically

Storage Backends

InMemory

Volatile, in-process storage. All data lost on exit. Best for testing and ephemeral caches.

storage = memory.InMemory(hv.MODEL_64K_8BIT, "my_store")

Embedded

Persistent, single-machine storage backed by an embedded key-value store. Suitable for local development and moderate-scale deployments.

storage = memory.Embedded(hv.MODEL_64K_8BIT, "/path/to/store")

ScyllaDB (Distributed)

Distributed storage via Cassandra-compatible ScyllaDB. For high-scale, multi-node deployments.

# Not exposed yet...

Selectors

ChunkSelectors are composable query builders for reading chunks from the substrate. Each selector defines how to locate and return matching chunks.

NNS (Near-Neighbor Search)

Wraps one or more attractors to perform near-neighbor search.

result = memory.first_picked(
    view, memory.nns(
    memory.set_members(memory.by_item_key("sets", "my_set")),
))

Each attractor conceptually provides “the center of attraction” for candidates: the NNS accepts one or more attractors, to perform the actual near-neighbor search work, by interacting with underlying associative index.

Implementation-wise, attractors are specialized selectors.

Forward attractors

Roughly forward attractors try to find parts from a given a composite.

memory.set_members(memory.by_item_key("sets", "my_set"))

memory.sequence_member(memory.by_item_key("seqs", "my_seq"), pos=2)

memory.tentacle(memory.by_item_key("records", "person"), key="name")

Reverse Attractors

Roughly reverse attractors try to locate composites given a part.

memory.set_attractor(memory.by_item_key("animals", "cat"), domain="sets")

memory.sequence_attractor(memory.by_item_key("animals", "cat"), pos=0, domain="seqs")

# NOTE the value is specified with another selector.
memory.octopus_attractor(key="color", value=memory.by_item_key("colors", "red"))

Analogical Reasoner

Analogical reasoner tries to perform analogical reasoning, like “A is to B as C is to ?”.

Given the analogy “king is to queen as man is to ?”

king   = hv.Sparkle(model, "role", "king")
queen  = hv.Sparkle(model, "role", "queen")
man    = hv.Sparkle(model, "role", "man")

# Analogy: "king is to queen as man is to ?"
#   src     = king   (the known source of the relationship)
#   feature = queen  (the known feature/attribute of src)
#   dst     = man    (the target; we want to find its corresponding feature)
#
# The attractor computes: dst ⊗ feature ⊗ src⁻¹
# This produces a code that should overlap with "woman"
memory.nns(
    memory.analogical_reasoner(memory.with_code(man), src=king, feature=queen)
)

Other Selectors

ByItemKey

Exact lookup by domain + pod.

sel = memory.by_item_key("animals", "cat")

ByItemDomain

All chunks in a given domain (prefix scan).

sel = memory.by_item_domain("animals")

WithCode / WithSparkle

Literal selector — returns a hypervector directly, no storage lookup.

sel = memory.with_code(some_hv)

sel = memory.with_sparkle("animals", "cat")

Joiner

Union of multiple selectors — returns results from each of the inner selectors.

sel = memory.joiner(
    memory.by_item_key("animals", "cat"),
    memory.by_item_key("animals", "dog"),
)

Range

Limits results to [start, start+limit). limit=0 (default) implies no limit, and iteration continue until there is no more results.

sel = memory.range_sel(
    memory.by_item_domain("animals"), start=0, limit=10)

OnlyDomain

Filters inner selector results by given domain.

sel = memory.only_domain(
    "animals", inner_selector)

Working with Results

FirstPicked — get the first match

Returns the first chunk matching the selector. Returns an error if nothing is found.

# Returns the first matching Chunk (with .id, .code, .note, .extra)
chunk = memory.first_picked(view, selector)
print(chunk.id, chunk.code, chunk.note)

Iterator — iterate all matches

mem_get — high-level batch read

results = storage.mem_get(selector)
for hv in results:
    print(hv)

Producers

ChunkProducers are write builders that create and persist chunks in the substrate. Each producer encapsulates the logic for constructing a specific type of chunk.

Producer Options

Producer options are additional information supplied to producer constructor to tweak behavior.

# `note` indiciates additional note for the new terminal chunk.
memory.new_terminal("d", "p", note="annotation")

# `semantic_indexing` indicates we need to index the semantic code
# (on top of the id vector).
memory.from_set_members("d", "p", members, semantic_indexing=True)

Concrete Producers

NewTerminal

Creates a chunk whose code equals its identity (a bare Sparkle). Useful for registering atoms/symbols.

with storage.new_mutable_view() as view:
    memory.mem_set(view, memory.new_terminal("fruits", "apple", note="an apple"))

NewLearner

Creates a fresh Learner chunk for online learning.

with storage.new_mutable_view() as view:
    memory.mem_set(view, memory.new_learner("learners", "my_learner", note="a learner"))

FromSetMembers

Creates a Set from stored members.

with storage.new_mutable_view() as view:
    memory.mem_set(
        view,
        memory.from_set_members(
            "sets",
            "fruit_set",
            memory.by_item_domain("fruits"),
        ))

FromSequenceMembers

Creates a Sequence from stored members with positional encoding.

with storage.new_mutable_view() as view:
    memory.mem_set(
        view,
        memory.from_sequence_members(
            "seqs",
            "greeting",
            memory.joiner(
                memory.by_item_key("words", "hello"),
                memory.by_item_key("words", "world"),
            ),
            start=0),
    )

FromKeyValues

Creates an Octopus (key-value composite) from keys and value selectors.

with storage.new_mutable_view() as view:
    memory.mem_set(
        view,
        memory.from_key_values(
            "records",
            "obj1",
            keys=["color", "shape"],
            values=memory.joiner(
                memory.by_item_key("colors", "red"),
                memory.by_item_key("shapes", "circle"),
            ),
        ))

ClusterUpdater

Feeds an observed chunk into an existing Learner, updating its accumulated code via bundling.

with storage.new_mutable_view() as view:
    memory.mem_set(view,
        memory.cluster_updater(
            learner=memory.by_item_key("learners", "my_learner"),
            observed=memory.by_item_key("fruits", "apple"),
            multiple=1,
        ))

Notebook Quick Start

This guide walks through using Kongming HV in a Jupyter notebook, cell by cell.

Tips

• Reproducibility: Use fixed seeds in SparseOperation for deterministic results across reruns.
• Visualization: Use pandas DataFrames for overlap matrices — they render nicely in Jupyter.
• Performance: The Rust backend is fast. Building 10,000 vectors takes under a second on MODEL_64K_8BIT.
• Model choice: Start with MODEL_64K_8BIT for exploration. Switch to MODEL_1M_10BIT or larger for production workloads.

Notebook Platforms

Setup and behavior differ across Jupyter, Google Colab, and Binder. This page covers the key differences.

Try Online

Notebook	Platform	Link
first.ipynb	Google Colab
first.ipynb	Binder
memory.ipynb	Google Colab
lisp.ipynb	Google Colab

Comparison

Jupyter (Local)

Install once in your terminal, then use in any notebook:

pip install kongming-rs-hv

# Cell 1 — no restart needed
from kongming import hv

For development workflows with frequent code changes, use autoreload:

%load_ext autoreload
%autoreload 2

Google Colab

Colab runs in the cloud with a fresh environment each session. Install in the first cell:

# Cell 1 — install
!pip install kongming-rs-hv

After the first install, Colab requires a runtime restart:

1. Go to Runtime → Restart runtime (or use the button Colab shows after install)
2. Then run the remaining cells

# Cell 2 — after restart
from kongming import hv
model = hv.MODEL_64K_8BIT

Subsequent sessions on the same notebook will need the install cell again — Colab does not persist pip packages across sessions.

Saving work: Use google.colab.drive to mount Google Drive for persistent storage:

from google.colab import drive
drive.mount('/content/drive')
# Then use paths like /content/drive/MyDrive/...

Binder

Binder builds a Docker image from your repo’s requirements.txt and launches a Jupyter server. No account needed.

• First launch: Takes 2–5 minutes to build the environment
• Subsequent launches: Faster if the image is cached
• No install needed: kongming-rs-hv is pre-installed from requirements.txt
• Ephemeral: All work is lost when the session times out (~10 min idle)

# Cell 1 — works immediately, no install
from kongming import hv

Choosing a Platform

Interactive Notebooks

For deeper walkthroughs, open these notebooks directly:

Notebook	Description	Colab
first.ipynb	Introduction to hypervectors, bind/bundle operations, and composites
memory.ipynb	In-memory and persistent storage, near-neighbor search with attractors, and export to disk
lisp.ipynb	VSA-based LISP interpreter where every data structure is a hypervector

See also: LISP Interpreter — a full application built on the core API.

Walkthrough

A step-by-step introduction to Kongming HV in a notebook, cell by cell.

Setup

# Cell 1: Install and import
# !pip install kongming-rs-hv pandas

from kongming import hv
import pandas as pd

model = hv.MODEL_64K_8BIT
so = hv.SparseOperation(model, 0, 1)

Building a Vocabulary

# Cell 2: Create vectors for a set of words
words = ["cat", "dog", "fish", "bird", "tree", "rock"]
vectors = {w: hv.Sparkle.from_word(model, "vocab", w) for w in words}

print(f"Created {len(vectors)} vectors")
print(f"Model: {model}, Cardinality: {hv.cardinality(model)}")

Output:

Created 6 vectors
Model: 1, Cardinality: 256

Similarity Matrix

# Cell 3: Compute pairwise overlap
data = {}
for w1 in words:
    data[w1] = {w2: hv.overlap(vectors[w1], vectors[w2]) for w2 in words}

pd.DataFrame(data, index=words)

Output:

The diagonal is 256 (cardinality = perfect self-overlap). Off-diagonal values are near 0-2 (random noise), confirming the vectors are near-orthogonal.

Learning from Observations

# Cell 4: Create a learner and feed it observations
learner = hv.Learner(model, hv.Seed128(0, so.uint64()))

# "cat" seen 3 times, "dog" once, "bird" once
for _ in range(3):
    learner.bundle(vectors["cat"])
learner.bundle(vectors["dog"])
learner.bundle(vectors["bird"])

print(f"Learner age: {learner.age()}")

Output:

Learner age: 5

Probing the Learner

# Cell 5: Check what the learner remembers
results = []
for w in words:
    ov = hv.overlap(learner, vectors[w])
    results.append({"word": w, "overlap": ov})

df = pd.DataFrame(results).sort_values("overlap", ascending=False)
df

Output:

“cat” has the highest overlap (seen 3x). “dog” and “bird” (seen 1x each) have moderate overlap. Unseen words are at noise level (~1).

Binding: Role-Filler Pairs

# Cell 6: Create a structured representation
#   "a cat that is red"
color_role = hv.Sparkle.from_word(model, "role", "color")
animal_role = hv.Sparkle.from_word(model, "role", "animal")

red = hv.Sparkle.from_word(model, "color", "red")
blue = hv.Sparkle.from_word(model, "color", "blue")
cat = vectors["cat"]

# Bind role with filler, then bundle the pairs
learner2 = hv.Learner(model, hv.Seed128(0, so.uint64()))
learner2.bundle(hv.Sparkle.bind(color_role, red))
learner2.bundle(hv.Sparkle.bind(animal_role, cat))

# Probe: "what color?"
query = hv.Sparkle.bind(learner2, color_role.power(-1))
print(f"red overlap:  {hv.overlap(query, red)}")   # high
print(f"blue overlap: {hv.overlap(query, blue)}")   # ~1
print(f"cat overlap:  {hv.overlap(query, cat)}")    # ~1

Python Quick Start

See also: Notebook Quick Start for interactive Jupyter walkthroughs.

Installation

PyPI

pip install kongming-rs-hv

Supported Platforms

Verifying Installation

import kongming
print(kongming.__version__)  # e.g. should be "3.6.5", as of Apr. 2026. Yours should be newer.

from kongming import hv
print(hv.MODEL_64K_8BIT)  # should print 1

Import Paths

The package exposes two main modules:

from kongming import hv       # hypervector operations
from kongming import memory   # storage and selectors

Model constants are available directly on hv:

hv.MODEL_64K_8BIT      # 1
hv.MODEL_1M_10BIT      # 2
hv.MODEL_16M_12BIT     # 3
hv.MODEL_256M_14BIT    # 4
hv.MODEL_4G_16BIT      # 5

Quick Example

A minimal example showing the core operations:

from kongming import hv

# Create hypervectors
a = hv.Sparkle.from_word(hv.MODEL_64K_8BIT, hv.d0(), "hello")
b = hv.Sparkle.from_word(hv.MODEL_64K_8BIT, hv.d0(), "world")
print(f'Overlap: {hv.overlap(a, b)}')  # Near orthogonal (~1)

# Bind: result is dissimilar to both inputs
bound = hv.bind(a, b)
print(f'{hv.overlap(bound, a)=}, {hv.overlap(bound, b)=}')  # ~1, ~1

# Bundle: result is similar to both inputs
bundled = hv.bundle(hv.Seed128(10, 1), a, b)
print(f'{hv.overlap(bundled, a)=}, {hv.overlap(bundled, b)=}')  # high, high

What’s Happening

1. Sparkle.from_word generates a deterministic hypervector from a word. Same word always produces the same vector.
2. Two unrelated vectors have near-zero overlap (~1) — random high-dimensional vectors are nearly orthogonal.
3. hv.bind(a, b) produces a vector dissimilar to both (low overlap). Binding is reversible.
4. hv.bundle(seed, a, b) produces a vector similar to both (high overlap). Different seeds produce different but equally valid results.

Walkthrough

A deeper exploration of the Python API, covering vector creation, similarity, random generation, power/permutation, and online learning.

Creating Vectors

from kongming import hv

model = hv.MODEL_64K_8BIT

# Create sparkles (atomic vectors) from words
cat = hv.Sparkle.from_word(model, "animals", "cat")
dog = hv.Sparkle.from_word(model, "animals", "dog")

# Same inputs always produce the same vector
cat2 = hv.Sparkle.from_word(model, "animals", "cat")
assert cat.stable_hash() == cat2.stable_hash()

Measuring Similarity

# Random vectors have ~1 overlap
print(hv.overlap(cat, dog))   # ≈ 1 (near-orthogonal)

# A vector is maximally similar to itself
print(hv.overlap(cat, cat))   # = 256 (= cardinality)

Using SparseOperation for Random Generation

so = hv.SparseOperation(model, 123, 456)

# Generate random sparkles
a = hv.Sparkle.random("my_domain", so)
b = hv.Sparkle.random("my_domain", so)

# Each call to so produces a new random seed
print(hv.overlap(a, b))  # ≈ 1

Power and Permutation

# Power creates a permuted vector
s = hv.Sparkle.from_word(model, "pos", "step")
s2 = s.power(2)
s3 = s.power(3)

# Different powers are near-orthogonal
print(hv.overlap(s, s2))   # ≈ 1
print(hv.overlap(s, s3))   # ≈ 1

# Inverse: power(-1) undoes power(1)
s_inv = s.power(-1)
# bind(s, s_inv) ≈ identity

Online Learning with Learner

learner = hv.Learner(model, hv.Seed128(0, 42))

# Feed observations one at a time
learner.bundle(cat)
learner.bundle(cat)   # seen twice — stronger signal
learner.bundle(dog)

# The learned vector is more similar to cat (seen 2x)
print(hv.overlap(learner, cat))  # higher
print(hv.overlap(learner, dog))  # lower but above random

Mexican Dollar

The “What’s the Dollar of Mexico?” problem is a classic demonstration of analogical reasoning with hypervectors. It shows how structured knowledge about countries can be encoded, and how algebraic operations can answer analogy questions without explicit programming.

The Problem

Given knowledge about three countries:

We want to answer questions like:

• “What is the Dollar of Mexico?” → Peso
• “What is the Washington DC of Mexico?” → Mexico City
• “What is the Dollar of Sweden?” → Krona

How It Works

Each country is encoded as a bundled set of role-filler bindings:

$$\text{US}=\sum _{\oplus }\left(\text{code}\otimes \text{usa},\text{capital}\otimes \text{dc},\text{currency}\otimes \text{dollar}\right)$$

$$\text{Mexico}=\sum _{\oplus }\left(\text{code}\otimes \text{mex},\text{capital}\otimes \text{mexico\_city},\text{currency}\otimes \text{peso}\right)$$

$$\text{Sweden}=\sum _{\oplus }\left(\text{code}\otimes \text{swe},\text{capital}\otimes \text{stockholm},\text{currency}\otimes \text{krona}\right)$$

To find “the Dollar of Mexico”, we compute a transfer vector from US to Mexico:

$$T_{\text{US}\to \text{Mexico}}=\text{Mexico}\oslash \text{US}$$

Then apply it to Dollar:

$$\text{result}=\text{dollar}\otimes T_{\text{US}\to \text{Mexico}}$$

The result will have high overlap with Peso — the analogical answer.

The same transfer works for Sweden:

$$T_{\text{US}\to \text{Sweden}}=\text{Sweden}\oslash \text{US}$$

$$\text{result}=\text{dollar}\otimes T_{\text{US}\to \text{Sweden}}\approx \text{krona}$$

Code (Manual)

The algebraic approach — compute the transfer vector directly:

from kongming import hv

model = hv.MODEL_64K_8BIT
so = hv.SparseOperation(model, "knowledge", 0)

# Create role markers
country_code = hv.Sparkle.from_word(model, "role", "country_code")
capital      = hv.Sparkle.from_word(model, "role", "capital")
currency     = hv.Sparkle.from_word(model, "role", "currency")

# Create fillers
usa         = hv.Sparkle.from_word(model, "country", "usa")
mex         = hv.Sparkle.from_word(model, "country", "mex")
swe         = hv.Sparkle.from_word(model, "country", "swe")
dc          = hv.Sparkle.from_word(model, "capital", "dc")
mexico_city = hv.Sparkle.from_word(model, "capital", "mexico_city")
stockholm   = hv.Sparkle.from_word(model, "capital", "stockholm")
dollar      = hv.Sparkle.from_word(model, "currency", "dollar")
peso        = hv.Sparkle.from_word(model, "currency", "peso")
krona       = hv.Sparkle.from_word(model, "currency", "krona")

# Encode each country as role-filler bundles
us_record = hv.bundle(hv.Seed128.random(so),
    hv.bind(country_code, usa),
    hv.bind(capital, dc),
    hv.bind(currency, dollar),
)
mexico_record = hv.bundle(hv.Seed128.random(so),
    hv.bind(country_code, mex),
    hv.bind(capital, mexico_city),
    hv.bind(currency, peso),
)
sweden_record = hv.bundle(hv.Seed128.random(so),
    hv.bind(country_code, swe),
    hv.bind(capital, stockholm),
    hv.bind(currency, krona),
)

# Transfer vector: Mexico / US
transfer_to_mexico = hv.release(mexico_record, us_record)

# "What's the Dollar of Mexico?"
mexican_dollar = hv.bind(dollar, transfer_to_mexico)
print(f"peso overlap:  {hv.overlap(mexican_dollar, peso)}")    # high!
print(f"dollar overlap: {hv.overlap(mexican_dollar, dollar)}")  # ~1 (noise)
print(f"krona overlap:  {hv.overlap(mexican_dollar, krona)}")   # ~1 (noise)

# "What's the Washington DC of Mexico?"
mexican_dc = hv.bind(dc, transfer_to_mexico)
print(f"mexico_city overlap: {hv.overlap(mexican_dc, mexico_city)}")  # high!

# Transfer to Sweden works the same way
transfer_to_sweden = hv.release(sweden_record, us_record)
swedish_dollar = hv.bind(dollar, transfer_to_sweden)
print(f"krona overlap: {hv.overlap(swedish_dollar, krona)}")  # high!

Code (with AnalogicalReasoner)

When records are stored in memory (as Octopus composites), the AnalogicalReasoner selector handles the transfer automatically:

from kongming import hv, memory

model = hv.MODEL_64K_8BIT
store = memory.InMemory(model)

keys = ["capital", "currency", "country_code"]

# Store individual fillers — NNS needs them as searchable items
fillers = {}
for word in ["dc", "USD", "USA", "mexicoCity", "MXN", "MEX",
             "stockholm", "SEK", "SWE"]:
    s = hv.Sparkle.from_word(model, 0, word)
    store.put(s)
    fillers[word] = s

# Store country records as Octopus composites
store.put(hv.Octopus(
    hv.Seed128("country", "USA"), keys,
    fillers["dc"], fillers["USD"], fillers["USA"],
))
store.put(hv.Octopus(
    hv.Seed128("country", "MEX"), keys,
    fillers["mexicoCity"], fillers["MXN"], fillers["MEX"],
))
store.put(hv.Octopus(
    hv.Seed128("country", "SWE"), keys,
    fillers["stockholm"], fillers["SEK"], fillers["SWE"],
))

# Retrieve stored records
us_code  = store.get("country", "USA").code
mex_code = store.get("country", "MEX").code
swe_code = store.get("country", "SWE").code

view = store.new_view()

# "What is the USD of Mexico?"
result = memory.first_picked_chunk(view,
    memory.nns(
        memory.analogical_reasoner(
            memory.with_code(mex_code),
            us_code,
            fillers["USD"],
        )
    )
)
print(result.id)  # → ✨:🌱MXN

# "What is the Washington DC of Mexico?"
result = memory.first_picked_chunk(view,
    memory.nns(
        memory.analogical_reasoner(
            memory.with_code(mex_code),
            us_code,
            fillers["dc"],
        )
    )
)
print(result.id)  # → ✨:🌱mexicoCity

# "What is the Dollar of Sweden?"
result = memory.first_picked_chunk(view,
    memory.nns(
        memory.analogical_reasoner(
            memory.with_code(swe_code),
            us_code,
            fillers["USD"],
        )
    )
)
print(result.id)  # → ✨:🌱SEK

The AnalogicalReasoner computes the transfer vector internally and uses near-neighbor search to find the best match in memory — no manual algebra needed.

Why It Works

The transfer vector $T=\text{Mexico}\oslash \text{US}$ captures the structural mapping between the two records. When applied to any filler from the US record, it maps it to the corresponding filler in the Mexico record — because the role-filler binding structure is preserved by the algebra.

This is a form of analogical reasoning: no explicit rules, no lookup tables — just algebraic operations on high-dimensional vectors.

See Also

• Concepts: Operators — algebraic foundations
• Operators — bind, release, bundle
• Octopus — key-value composite used for country records
• Memory: Selectors — analogical_reasoner, nns, with_code
• Near-neighbor search — how the reasoner finds answers

LISP Interpreter

Bulk Storage Benchmark

This example populates a storage with a large number of random terminal chunks, then queries a few by key to verify correctness. It demonstrates how to batch-create items and measure throughput.

Note associative index is also prepared in the process, and near-neighbor search is available immediately upon successful conclusion of all writing.

Motivated readers can further improve this script to test various producers or selectors.

Script

#!/usr/bin/env python3
"""Populate local storage with random terminal chunks and verify retrieval."""

import argparse
import shutil
import tempfile
import time
from kongming import hv, memory


def main():
    parser = argparse.ArgumentParser(description="Bulk storage benchmark")
    parser.add_argument(
        "-n", "--count", type=int, default=10_000,
        help="Number of terminal chunks to create (default: 10000)",
    )
    parser.add_argument(
        "--model", type=int, default=hv.MODEL_1M_10BIT,
        help="HV model (default: MODEL_1M_10BIT)",
    )
    parser.add_argument(
        "--domain", type=str, default="bench",
        help="Domain name for all chunks (default: bench)",
    )
    parser.add_argument(
        "--backend", type=str,
        choices=["inmemory", "embedded"],
        default="inmemory",
        help="Storage backend (default: inmemory)",
    )
    parser.add_argument(
        "--path", type=str, default=None,
        help="Disk path for embedded backend (default: temp directory)",
    )
    args = parser.parse_args()

    # --- Create storage ---
    tmpdir = None
    if args.backend == "embedded":
        if args.path:
            path = args.path
        else:
            tmpdir = tempfile.mkdtemp()
            path = f"{tmpdir}/bench_store"
        storage = memory.Embedded(args.model, path)
        print(f"Backend: Embedded (path={path})")
    else:
        storage = memory.InMemory(args.model)
        print("Backend: InMemory (BTreeMap, pure in-memory)")

    # --- Write phase ---
    print(f"Writing {args.count:,} terminal chunks …")
    t0 = time.perf_counter()
    for i in range(args.count):
        storage.mem_set(memory.new_terminal(args.domain, str(i)))

    elapsed = time.perf_counter() - t0
    rate = args.count / elapsed
    print(f"  done in {elapsed:.2f}s  ({rate:,.0f} chunks/s)")
    print(f"  item_count = {storage.item_count():,}")

    # --- Read phase: spot-check a few items ---
    spot_checks = range(0, args.count, args.count // 100)
    print(f"Spot-checking keys: {spot_checks}")
    for idx in spot_checks:
        expected = hv.Sparkle.from_word(args.model, args.domain, str(idx))
        chunk = storage.get(args.domain, str(idx))
        if not hv.equal(chunk.id, expected):
            print(f"mismatch at key {idx}: {chunk}")

    print("All checks passed.")

    # --- Cleanup ---
    if tmpdir:
        del storage
        shutil.rmtree(tmpdir)


if __name__ == "__main__":
    main()

Usage

# Default: 10K chunks, in-memory storage substrate.
python bulk_storage.py

# Embedded (disk-backed storage substrate).
python bulk_storage.py --backend embedded

# Embedded with a specific path (tip: use a tmpfs mount for near-in-memory speed)
python bulk_storage.py --backend embedded --path /dev/shm/my_bench

# Custom count
python bulk_storage.py -n 100000

# Different model, 1 implies MODEL_64K_8BIT model, etc.
python bulk_storage.py -n 10000 --model 1
